Solar Inverter (with mppt controller inside)
Official Store
₦750,000.00₦850,000.00 (-12%)
Single, No Parallled Function
Model:J6200HPC
Output power : 5500W
Output voltage: 220V-240v
Single phase
New Arrival jsdsolar 4KW 24V Hybrid Solar Inverter MPPT 100A Solar Charger 500VDC PV Input Off Grid Pure Sine Wave with Wifi
Express Shipping
Pure sine wave inverter ★ Configurable dual AC output ★ Charging current up to 100A ★ Compatible with various battery types ★ Communicate with lithium battery BMS ★ With lithium battery BMS activation function ★ Over temperature / Over load / Over voltage / Short circuit protection ★ Advanced MPPT technology with an efficiency of 99.9% ★ Easy to install and operate
Models | J4000HC |
Rated input voltage | 220/230VAC |
Input voltage range | 90-280VAC |
Frequency | 50Hz/ 60Hz |
Bypass Overload Current | 20A |
INVERTER OUTPUT | |
Rated output power (W) | 4000W |
Rated output voltage (VAC) | 230VAC |
Output Topology | L + N + PE |
Switch Time | 10ms（Typical） |
Waveform | Pure sine wave |
BATTERY | |
Battery Type | Lithium / Lead -acid / User-define |
Rated Battery Voltage | 24Vdc |
Max PV charge current | 100A |
Max Mains/Generator Charging Current | 100A |
Max Hybrid Charging Current | 100A |
PV INPUT | |
PV Charging method | MPPT |
PV Maximum Input Power | 5000W |
PV Maximum Input Current | 18A |
Max PV Voltage | 500Vdc |
MPPT Voltage Range | 40-450Vdc |
MPPT Tracking Efficiency | 99% |
Max. Battery Inverter Efficiency | 92.7% |
COMMUNICATION and GENERAL | |
Embedded Interfaces | RS485 / CAN / USB / Dry contact |
External Modules (Optional) | Wifi |
Operating Temperature Range | -10~50℃ |
Storage Temperature | -15~60℃ |
Humidity range | 5% to 95% (Conformal coating protection) |
Cooling Method | Intelligent Fan |
Size (L*W*D) | 448*298.8*115mm |
Protection Degree | IP20 |
Net Weight | 7.3kg |
Additional information
| Weight | 7.3 kg |
|---|---|
| Dimensions | 448 × 298.8 × 115 cm |
